LYRAS DUO
Product Description
Aluminum injection body
Tempered glass
Constant current LED driver
Electrostatic powder coating paint
Optional body colors
ENEC Standards
Installation
RECESSED INSTALLATION IN THE CEILING DRIVER HOUSING IS SEPARATE FOR EASY INSTALLATION
Connection
3X0,75 mm2 CABLE
Design
RECTANGLE SHAPE ADJUSTABLE DOWNLIGHT MADE OF ALUMINIUM IN WHITE COLOR AS STANDARD OPTION WITH METALLISED REFLECTOR AND CLEAR LENSES
Reflector
Reflector of matt metallised aluminium in white color as standard
Light distribution
DIRECT BEAM ANGLE
Versions
Documents
Technical Drawings
Version Product Code
Version Power
Version CCT
Version Dimensions
Version Lumen
LYRS2.14.120x200.N.4.23
14 W
4000 K
120X240X90 mm
1540 lm
LYRS2.14.120x200.N.4.37
14 W
4000 K
120X240X90 mm
1520 lm
LYRS2.14.120x200.N.4.51
14 W
4000 K
120X240X90 mm
1500 lm
LYRS2.20.120x240.N.4.23
20 W
4000 K
120X240X90 mm
2140 lm
LYRS2.20.120x240.N.4.37
20 W
4000 K
120X240X90 mm
2120 lm
LYRS2.20.120x240.N.4.51
20 W
4000 K
120X240X90 mm
2100 lm
